PET Woven Network Tube
Lightweight abrasion protection and bundling for wire harness assemblies.
Harness
PET Woven Network Tube
Lightweight abrasion protection and bundling for wire harness assemblies.
Harness
Typical Parameters
| Parameter | Typical value |
|---|
| Material | PET monofilament |
|---|
| Working temperature | Wide operating temperature range |
|---|
| Voltage / dielectric | Mechanical protection |
|---|
| Size range | Nominal 1/8 in to 2-1/2 in; expanded ID 1-105 mm |
|---|
| Structure | PET expandable open-weave braided sleeving |
|---|
OEM note: Detailed size table, validation data and custom packing can be confirmed by project.
Why this product
- Supports OEM insulation, protection and routing requirements.
- Suitable for sourcing, engineering validation and sample review.
- Can be matched with your application temperature, voltage and routing needs.
Typical applications
- Automotive and EV electrical systems
- Motors, transformers and industrial equipment
- Wire harness, appliance and custom assembly projects
Frequently Asked Questions
Frequently Asked Questions
What is PET braided sleeving used for?
PET braided sleeving is used for lightweight abrasion protection, bundling and visual finishing of wire harness assemblies in vehicles, appliances, cabinets and industrial equipment.
When is braided sleeving better than corrugated tubing?
Braided sleeving is useful when flexibility, light abrasion protection and appearance matter. Corrugated tubing is often selected when stronger mechanical routing protection or defined conduit behavior is needed.
What dimensions are needed for braided sleeving samples?
Send bundle diameter, expansion requirement, route length, abrasion condition, temperature, color and packing or cut-length preference.
What is PET woven network tube and what is it used for?
PET woven network tube (PET braided sleeving) is made from monofilament polyester yarn woven into an expandable mesh. It is used for wire harness bundling, cable management and abrasion protection in automotive, electronics and industrial equipment. It is lightweight, flexible and expandable to accommodate varying bundle sizes.
What is the difference between PET braided sleeving and silicone fiberglass sleeving?
PET braided sleeving is a polyester monofilament mesh rated to approximately 150 C, offering good abrasion resistance and expandability at lower cost. Silicone fiberglass sleeving is a braided fiberglass tube coated with silicone rubber, rated to 200 C with higher dielectric strength and UL recognition under UL 1441. Choose PET for general bundling; choose silicone fiberglass for higher temperature and voltage insulation.
What temperature can PET woven sleeving withstand?
PET woven network tube typically withstands temperatures up to 150 C. For applications above 150 C, consider silicone fiberglass sleeving (200 C), high-temperature fiberglass sleeving, or PTFE tubing depending on the temperature and dielectric requirement.
